User variables

10.6 Program PUD

Milling

446 Operating Manual, 03/2010, 6FC5398-7CP20-1BA0

Proceed as follows

1. Select the "Parameter" operating area.

2. Press the "User variable" softkey.

3. Press the "Local LUD" softkey.

10.6 Program PUD

Program-global user data

PUDs are global part program variables (Program User Data). PUDs are valid in all main

programs and subroutines, where they can also be written and read.

Machine manufacturer

Please refer to the machine manufacturer's specifications.

Procedure

1. Select the "Parameter" operating area.

2. Press the "User variable" softkey.

3. Press the "Program PUD" softkey.
