Page #596 background imageLoading...
Page #596 background image
Alarms, error messages, and system alarms
20.8 Remote diagnostics
Milling
596 Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
Data Meaning
Send interval Cycle in which the message is sent to the remote PC in seconds
Ping send
data
Message for the remote PC
Procedure
1. The "Remote diagnostics (RCS)" window is opened.
2. Press the "Request remote diagnostics" softkey.
The "Request remote diagnostics" window is displayed.
3. Press the "Change" softkey if you would like to edit the values.
4. Press the "OK" softkey.
The request is sent to the remote PC.
References
Commissioning Manual SINUMERIK Operate (IM9) / SINUMERIK 840D sl
20.8.4 Exit remote diagnostics
Procedure
1. The "Remote diagnostics (RCS)" is opened and it is possible that
remote monitoring or remote access is active.
2. Block modem access if access via modem is to be blocked .
- OR -
In the "Remote diagnostics (RCS)" window, reset the access rights to
"Permit no remote access" .
