Programming technological functions (cycles)
8.1 Drilling
Milling
Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
285
Parameter Description Unit
X0
Y0
X coordinate for 1st position (abs.)
Y coordinate for 1st position (abs.)
mm
mm
- (only for
ShopMill)
L1
... L7
C1
... C7
Polar coordinates, additional. Positions, when selecting "polar"
Length (abs.)
Angle (abs.)
mm
Degrees
X1 ... X7
Y1
... Y8
X coordinate for further positions (abs. or inc.)
Y coordinate for further positions (abs. or inc.)
mm
mm
8.1.11 Position pattern Line (HOLES1), Grid or Frame (CYCLE801)
Function
You can program the following pattern using the "Position pattern" cycle:
● Line (HOLES1)
In the "Line" selection option you can program any number of positions at equal distances
along a line.
● Grid (CYCLE801)
You can use the "Grid" selection option to program any number of positions spaced at an
equal distance along one or several parallel lines.
If you want to program a rhombus-shaped grid, enter angle αX or αY.
● Frame (CYCLE801)
You can use the "Frame" selection option to program any number of positions spaced at
an equal distance on a frame. The spacing may be different on both axes.
If you want to program a rhombus-shaped frame, enter angle αX or αY.
Procedure
1. The part program or ShopMill program to be processed has been
created and you are in the editor.
2. Press the "Drilling" softkey.
3. Press the "Positions" and "Line" softkeys.
The "Position pattern" input window opens.
