15.3 Machine control panel menu

Milling

Operating Manual, 03/2010, 6FC5398-7CP20-1BA0

539

15.3 Machine control panel menu

Here you select keys from the machine control panel which are reproduced by the software

by touch operation of the relevant softkeys.

See chapter "Controls on the machine control panel" for a description of the individual keys.

Note

PLC interface signals that are triggered via the softkeys of the machine control panel menus

are edge triggered.

Showing and hiding

The user menu key "U" displays the CPF softkey bar (vertical softkey bar) and the user

softkey bar (horizontal softkey bar).

You can expand the user softkey bar to display eight additional softkeys via

the menu forward key.

You use the "Back" softkey to hide the menu bar again.
