Teaching in a program
11.3 Inserting a block
Milling
Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
451
11.3.1 Input parameters for teach-in blocks
Parameters for teach-in of position and teach-in of G0, G1, and circle end position CIP
Parameter Description
X Approach position in X direction
Y Approach position in Y direction
Z Approach position in Z direction
F
Feedrate (mm/r; mm/min) - only for teach-in of G1 and circle end position CIP
Parameters for teach-in of circle intermediate position CIP
Parameter Description
I Coordinate of the circle center point in the X direction
J Coordinate of the circle center point in the Y direction
K Coordinate of the circle center point in the Z direction
Transition types for teach-in of position and teach-in of G0 and G1, and ASPLINE
The following parameters are offered for the transition:
Parameter Description
G60 Exact stop
G64 Corner rounding
G641 Programmable corner rounding
G642 Axis-specific corner rounding
G643 Block-internal corner rounding
G644 Axis dynamics corner rounding
Motion types for teach-in of position and teach-in of G0 and G1
The following motion parameters are offered:
Parameter Description
CP Path-synchronous
PTP Point-to-point
PTPG0 Only G0 point-to-point
