Tool management

12.7 Tool data OEM

Milling

Operating Manual, 03/2010, 6FC5398-7CP20-1BA0

485

References

Commissioning Manual SINUMERIK Operate / SINUMERIK 840D sl

Multiple load points

If you have configured several loading points for a magazine, then the "Loading Point

Selection" window appears after pressing the "Load" softkey.

Select the required load point and confirm with the "OK" softkey.

12.7 Tool data OEM

You have the option of configuring the list according to your requirements:

References

For more information, see the following references:

Commissioning Manual SINUMERIK Operate / SINUMERIK 840D sl

Procedure

1. Select the "Parameter" operating area.

2. Press the "OEM Tool" soft key.
