Machining the workpiece

4.11 Displaying G Functions and Auxiliary Functions

Milling

166 Operating Manual, 03/2010, 6FC5398-7CP20-1BA0

Procedure

1. Select the "Machine" operating area.

...

2. Press the <JOG>, <MDA> or <AUTO> key.

3. Press the ">>" and "All G functions" softkeys.

The "G Functions" window is opened.

4.11.3 Auxiliary functions

Auxiliary functions include M and H functions preprogrammed by the machine manufacturer,

which transfer parameters to the PLC to trigger reactions defined by the manufacturer.

Displayed auxiliary functions

Up to five current M functions and three H functions are displayed in the "Auxiliary

Functions" window.

Procedure

1. Select the "Machine" operating area.

...

2. Press the <JOG>, <MDA> or <AUTO> key.
