Siemens SINUMERIK 840D

Programming technological functions (cycles)
8.7 Further cycles and functions ShopMill
Milling
Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
423
8.7.4 Scaling
You can specify a scale factor for the active machining plane as well as for the tool axis. The
programmed coordinates are then multiplied by this factor.
New scaling Additive scaling
Parameter Description Unit
Scaling
 New
New scaling
 Additive
Additive scaling
XY Scale factor XY
Z Scale factor Z
