Page #428 background imageLoading...
Page #428 background image
Programming technological functions (cycles)
8.7 Further cycles and functions ShopMill
Milling
428 Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
Parameter Description Unit
F
Machining feedrate mm/rev
mm/min
mm/tooth
Input defining which side of the contour the cutter travels in the programmed
direction:
Radius compensation to right of contour
Radius compensation to left of contour
Radius compensation off
Radius compensation
The previously programmed setting for radius compensation is used.
8.7.8 Programming a circle with known center point
The tool travels along a circular path from its actual position to the programmed circle end
point. You must know the position of the circle center point. The control calculates the radius
of the circle/arc on the basis of your interpolation parameter settings.
The circle can only be traversed at machining feedrate. You must program a tool before the
circle can be traversed.
Procedure
1. The ShopMill program to be edited has been created and you are in
the editor.
2. Press the menu forward key and the "Straight Circle" softkey.
3. Press the "Circle center point" softkey.
Parameter Description Unit
The tool travels in the programmed direction from the circle starting point to its end
point. You can program this direction as clockwise or counterclockwise.
Clockwise direction of rotation
Direction of rotation
Counterclockwise direction of rotation
X
Target position X (abs) or target position X referred to the last programmed
position (inc)
mm
