Simulating machining

5.8 Changing and adapting a simulation graphic

Milling

Operating Manual, 03/2010, 6FC5398-7CP20-1BA0

189

Press the "Details" and "Auto zoom" softkeys if you wish to

automatically adapt the segment to the size of the window.

The automatic scaling function "Fit to size" takes account of the

largest expansion of the workpiece in the individual axes.

Note

Selected section

The selected sections and size changes are kept as long as the program is selected.

5.8.2 Panning a graphical representation

Precondition

The simulation or the simultaneous recording is started.

Procedure

1. Press a cursor key if you wish to move the graphic up, down, left, or

right.
