Simulating machining

5.8 Changing and adapting a simulation graphic

Milling

188 Operating Manual, 03/2010, 6FC5398-7CP20-1BA0

Press the <CTRL> and <S> keys simultaneously to enable and

disable the single block mode.

5.8 Changing and adapting a simulation graphic

5.8.1 Enlarging or reducing the graphical representation

Precondition

The simulation or the simultaneous recording is started.

Procedure



...



1. Press the <+> and <-> keys if you wish to enlarge or reduce the

graphic display.

The graphic display enlarged or reduced from the center.

- OR -

Press the "Details" and "Zoom +" softkeys if you wish to increase the

size of the segment.

- OR -

Press the "Details" and "Zoom -" softkeys if you wish to decrease the

size of the segment.

- OR -
