Execution in manual mode
3.6 Simple face milling of workpiece
Milling
130 Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
Parameter Description Unit
Direction Preferred direction of rotation for 2 alternatives (swiveling axis-by-axis)
+: Larger angle of the axis on the scale of the swivel head / swivel table
-: Smaller angle of the axis on the scale of the swivel head / swivel table
Tool Correction: The position of the tool tip is maintained during swiveling
No correction: The position of the tool tip changes during swiveling
3.6 Simple face milling of workpiece
You can use this cycle to face mill any workpiece. A rectangular surface is always machined.
Selecting the machining direction
In the "Direction" field, using the select key, select the desired machining direction:
● Same direction of machining
● Alternating direction of machining
Selecting limits
You can select the limits using the appropriate softkeys:
Left
Bottom
Top
Right
See also
Face milling (CYCLE61) (Page 289)
Prerequisite
To carry out simple stock removal of a workpiece in manual mode, a measured tool must be
in the machining position.
