Teaching in a program
11.5 Editing a block
Milling
456 Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
7. Press the "Accept" softkey.
A new program block will be inserted at the cursor position.
- OR -
Press the "Cancel" softkey to cancel your input.
Note
Selection of axes and parameters for teach-in
You can select the axes to be included in the teach-in block in the "Settings" window.
You also specify here whether motion and transition parameters are offered for teach-in.
11.5 Editing a block
You can only overwrite a program block with a teach-in block of the same type.
The axis values displayed in the relevant window are actual values, not the values to be
overwritten in the block.
Note
If you wish to change any variable in a block in the program block window other than the
position and its parameters, then we recommend alphanumerical input.
Requirement
The program to be edited is selected.
Proceed as follows
1. Select the "Machine" operating area.
2.
Press the
<AUTO> or
<MDA>
key.
3. Press the <TEACH IN> key.
