Tool management

12.4 Tool dimensioning

Milling

Operating Manual, 03/2010, 6FC5398-7CP20-1BA0

465

12.4 Tool dimensioning

This section provides an overview of the dimensioning of tools.

Tool types

'LDPHWHU

/HQJWK

Figure 12-5 End mill (Type 120)

/HQJWK

'LDPHWHU

2XWHUGLDPHWHU

Figure 12-6 Face mill (Type 140)
