Introduction
1.4 User interface
Milling
Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
47
1.4.14 Online help in SINUMERIK Operate
A comprehensive context-sensitive online help is stored in the control system.
A brief description is provided for each window and, if required, step-by-step instructions
for the operating sequences.
A detailed help is provided in the editor for every entered G code. You can also display all
G functions and take over a selected command directly from the help into the editor.
A help page with all parameters is provided on the input screen in the cycle programming.
Lists of the machine data
Lists of the setting data
Lists of the drive parameters
List of all alarms
Procedure
Calling context-sensitive online help
1. You are in an arbitrary window of an operating area.
2. Press the <HELP> key or on an MF2 keyboard, the <F12> key.
The help page of the currently selected window is opened in a
subscreen.
3. Press the "Full screen" softkey to use the entire user interface for the
display of the online help.
Press the "Full screen" softkey again to return to the subscreen.
4. If further helps are offered for the function or associated topics,
position the cursor on the desired link and press the "Follow
reference" softkey.
The selected help page is displayed.
5. Press the "Back to reference" softkey to jump back to the previous
help.
