Tool management
12.12 Displaying tool details
Milling
Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
493
Press the "Magazine location" softkey if you wish to search for a
specific magazine location or a specific magazine.
- OR -
Press the "Empty location" softkey if you wish to search for a specific
empty location.
12.12 Displaying tool details
All of the parameters of the selected tool are listed in the "Tool details - all parameters"
window.
The parameters are displayed, sorted according to the following criteria
● Tool data
● Cutting edge data
● Monitoring data
Protection level
You require access level, keyswitch 3 (protection level 4) in order to edit the parameters in
the detail window.
Machine manufacturer
Please refer to the machine manufacturer's specifications.
Procedure
...
1. The tool list, the wear list, the OEM tool list or the magazine is
opened.
2. Position the cursor to the desired tool.
3. If you are in the tool list or in the magazine, press the ">>" softkey and
"Details".
- OR -
If you are in the wear list or OEM tool list, press the "Details" softkey.
