Page #34 background imageLoading...
Page #34 background image
Introduction
1.4 User interface
Milling
34 Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
See also
Overview (Page 69)
Work offsets (Page 100)
1.4.4 T,F,S window
The most important data concerning the current tool, the feedrate (path feed or axis feed in
JOG) and the spindle are displayed in the T, F, and S windows.
Tool data
Display Meaning
T
Tool name Name of current tool
Location Location number of current tool
D Cutting edge of the current tool
The tool is displayed with the associated tool type symbol corresponding to
the actual coordinate system in the selected cutting edge position.
If the tool is swiveled, then this is taken into account in the display of the
cutting edge position.
In DIN-ISO mode the H number is displayed instead of the cutting edge
number.
H H number (tool offset data record for DIN-ISO mode)
If there is a valid D number, this is also displayed.
Ø Diameter of current tool
R Radius of the actual tool
Z Z value of the actual tool
X X value of the actual tool
Feed data
Display Meaning
F
Feed disable
Actual feed value
If several axes traverse, is displayed for:
"JOG" mode: Axis feed for the traversing axis
"MDA" and "AUTO" mode: Programmed axis feed
Rapid traverse G0 is active
0.000 No feed is active
Override Display as a percentage
