Programming technological functions (cycles)

8.7 Further cycles and functions ShopMill

Milling

Operating Manual, 03/2010, 6FC5398-7CP20-1BA0

421

8.7.2 Translation

For each axis, you can program an offset of the zero point.

New offset

Additive offset

Parameter Description Unit

Offset

 New

New offset

 Additive

Additive offset

X Offset X mm

Y Offset Y mm

Z Offset Z mm
