Programming technological functions (cycles)

8.7 Further cycles and functions ShopMill

Milling

422 Operating Manual, 03/2010, 6FC5398-7CP20-1BA0

8.7.3 Rotation

You can rotate every axis through a specific angle. A positive angle corresponds to

counterclockwise rotation.

New rotation

Additive rotation

Parameter Description Unit

Rotation

 New

New rotation

 Additive

Additive rotation

X Rotation around X Degrees

Y Rotation around Y Degrees

Z Rotation around Z Degrees
