Alarms, error messages, and system alarms
20.5 Version
Milling
588 Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
20.5 Version
20.5.1 Displaying version data
The following components with the associated version data are specified in the "Version
data" window:
● System software
● Basic PLC program
● PLC user program
● System extensions
● OEM applications
● Hardware
Information is provided in the "Nominal version" column as to whether the versions of the
components deviate from the version supplied on the CompactFlash Card.
The version displayed in the "Actual version" column matches the version of
the CF card.
The version displayed in the "Actual version" column does not match the
version of the CF card.
You may save the version data. Version displays saved as text files can be further
processed as required or sent to the hotline in the event of an error.
Procedure
1. Select the "Diagnosis" operating area.
2. Press the "Version" softkey.
The "Version Data" window appears.
Data from the available components are displayed.
3. Select the component for which you would like more information.
4. Press the "Details" softkey, in order to receive more exact information
on the components displayed.
