Introduction
1.4 User interface
Milling
42 Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
1.4.10 Touch operation
If you have an operator panel with a touch screen, you can perform the following functions
with touch operation:
Operating area switchover
You can display the operating area menu by touching the display symbol for
the active operating area in the status display.
Channel switchover
You can switch over to the next channel by touching the channel
display in the status display.
1.4.11 Changing the user interface language
Procedure
1. Select the "Startup" operating area.
2. Press the "Change language" softkey.
The "Language selection" window opens. The language set last is
selected.
3. Position the cursor on the desired language.
4. Press the "OK" softkey.
- OR -
Press the <INPUT> key.
The user interface changes to the selected language.

Siemens SINUMERIK 840D Specifications

General

Series	SINUMERIK 840D
Axes	Up to 31
Channels	Up to 10
Operating System	Windows-based
Power Supply	24 V DC
Control Unit Type	CNC
Interface	Ethernet, PROFIBUS
Display	TFT color display
Interpolation	Spline
PLC	Integrated PLC
Data Storage	CompactFlash, USB
