Setting up drives
14.2 Setting up drives
Milling
Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
533
Entry Meaning
Icon file name. Is displayed on the softkey.
Icon file name. Is displayed on the softkey.
Text file slpmdialog
Text context SlPmDialog
File for softkey dependent on the language. If nothing is
specified in the input fields, the text appears on the softkey as
was specified in the input field "Softkey text".
If your own text files are saved, then the text ID, which is used
to search for the text file, is specified in the "Softkey text" input
field.
User name
Password
Enter the user name and the corresponding password for
which the directory is enabled on the server. The password is
displayed in encoded form as as string of "*" characters and is
stored in the "logdrive.ini" file.
Error messages
Error message Meaning
Error occurred when closing a connection An existing drive was not able to be deactivated.
Error occurred when establishing a connection. Drive connection was not able to be established.
Error occurred while establishing a connection:
Incorrect entry or no authorization.
Drive connection was not able to be established.
Incorrect data The entered data are either incorrect or
inconsistent.
Function not available The function is not supported with the current
software release.
Unknown error - error code:%1 Error was not able to be assigned.
Procedure
1. Select the "Start-up" operating area.
2. Press the "HMI" and "Log. drive" softkeys.
The "Set Up Drives" window opens.
3. Select the data for the corresponding drive or enter the necessary
data.
