Siemens SINUMERIK 840D Operating Manual

Setting up drives
14.2 Setting up drives
Milling
534 Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
4. Press the "Activate drive" softkey.
The drive is activated.
The operating system now checks the entered data and whether the
connection is established. An OK message is output in the dialog line if
an error is not identified.
The drive can be accessed.
- OR -
If the operating system identifies an error, then you receive an error
message.
Press the "OK" softkey.
You then return to the "Configure drives" window. Check and correct
your entries and re-activate the drive.
If you press the "OK" softkey, the modified data are accepted without
any feedback message. You do not receive any message about a
successful or unsuccessful connection.
If you press the "Cancel" softkey, then all of the data that has not been
activated is rejected.

Siemens SINUMERIK 840D Specifications

General

Series	SINUMERIK 840D
Axes	Up to 31
Channels	Up to 10
Operating System	Windows-based
Power Supply	24 V DC
Control Unit Type	CNC
Interface	Ethernet, PROFIBUS
Display	TFT color display
Interpolation	Spline
PLC	Integrated PLC
Data Storage	CompactFlash, USB
