Programming technological functions (cycles)
8.5 Contour turning - only for G code programs
Milling
402 Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
Parameters Description Unit
D Maximum depth infeed - (only for ∇) mm
XDA 1. Grooving limit tool (abs) – (only for face machining direction) mm
XDB 2. Grooving limit tool (abs) – (only for face machining direction) mm
UX or U Finishing allowance in X or finishing allowance in X and Z – (only for ∇) mm
UZ Finishing allowance in Z – (only for UX) mm
DI For zero: Continuous cut - (only for ∇) mm
BL Description of unmachined part
Cylinder
Allowance
Contour
XD - (only for unmachined part description, cylinder and allowance)
For unmachined part description, cylinder
– Allowance or cylinder dimension ∅ (abs)
– Allowance or cylinder dimension (inc)
For unmachined part description, allowance
– Allowance on the contour ∅ (abs)
– Allowance on the contour (inc)
mm
ZD - (only for unmachined part description, cylinder and allowance)
For unmachined part description, cylinder
Allowance or cylinder dimension (abs or inc)
For unmachined part description, allowance
Allowance on the contour (abs or inc)
mm
Allowance Allowance for pre-finishing - (only for ∇∇∇)
Yes
U1 contour allowance
No
mm
U1 Compensation allowance in X and Z direction (inc) – (only for allowance)
Positive value: Compensation allowance is kept
Negative value: Compensation allowance is removed in addition to finishing
allowance
mm
Set machining area
limits
Set machining area limits
Yes
– XA: 1. Limit XA ∅
– XB: 2. Limit XB ∅ (abs) or 2nd limit referred to XB (inc)
– ZA: 1. Limit ZA
– ZB: 2. Limit ZB (abs) or 2nd limit referred to ZB
No
N Number of grooves
DP Distance between grooves mm
