Programming technological functions (cycles)
8.2 Milling
Milling
306 Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
Machining type
You can select the machining mode for milling the longitudinal slot as follows:
● Roughing
During roughing, the individual planes of the slot are machined one after the other until
depth Z1 is reached.
● Finishing
During finishing, the edge is always machined first. The slot edge is approached on the
quadrant, which joins the corner radius. In the last infeed, the base is finished from the
center out.
● Finishing of edge
Edge finishing is performed in the same way as finishing, except that the last infeed
(finish base) is omitted.
● Chamfer
Chamfering involves edge breaking at the upper edge of the longitudinal slot.
Procedure
1. The part program or ShopMill program to be processed has been
created and you are in the editor.
2. Press the "Milling" softkey.
3. Press the "Groove" and "Longitudinal groove" softkeys.
The "Longitudinal Groove (SLOT1)" input window opens.
Parameters, G code program Parameters, ShopMill program
PL Machining plane T Tool name
Milling direction D Cutting edge number
RP Retraction plane mm F Feedrate mm/min
mm/rev
SC Safety clearance mm S / V Spindle speed or constant
cutting rate
rpm
m/min
F Feedrate mm/min
