Tool management

12.5 Tool list

Milling

Operating Manual, 03/2010, 6FC5398-7CP20-1BA0

481

Hiding magazines

Deactivate the checkbox next to the magazines that you do not want to appear in

the magazine list.

The magazine selection behavior with multiple magazines can be configured in different

ways.

Machine manufacturer

Please refer to the machine manufacturer's specifications.

References

For a description of configuration options, refer to the

Commissioning Manual SINUMERIK Operate / SINUMERIK 840D sl
