Easy Message (828D only)
16.4 Setting-up events
Milling
Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
547
● Measuring cycle messages for tools
An SMS is sent if measuring cycle messages are output that involve tools.
● Measuring cycle messages for workpieces
An SMS is sent if measuring cycle messages are output that involve workpieces.
● Sinumerik messages/alarms (error when executing)
An SMS is sent if NCK alarms or messages are output that cause the machine to come to
a standstill.
● Machine faults
An SMS is sent if PLC alarms or messages are output that cause the machine to come to
a standstill (i.e. PLC alarms with Emergency Off response).
● Maintenance intervals
An SMS is sent if the service planner registers pending maintenance work.
● Additional alarm numbers:
Here, specify additional alarms where you should be notified if they occur.
You can enter individual alarms, several alarms or alarm number ranges.
Examples:
1234,400
1000-2000
100,200-300
Requirement
● The user profile window is opened.
● You selected the event "Measuring cycle messages for tools", "Measuring cycle
messages for workpieces", "Sinumerik messages/alarms (errors when executing)",
"Machine faults" or "Maintenance intervals".
Editing events
1. Activate the required check box and press the "Details" softkey.
The appropriate window opens (e.g. "Measuring cycle messages for
workpieces") and shows a list of the defined alarm numbers.
2. Select the corresponding entry and press the "Delete" softkey to
remove the alarm number from the list.
- OR -
Then press the "New" softkey if you wish to create a new entry.
The "Create new entry" window opens.
Enter the data and press the "OK" softkey to add the entry to the list.
