Execution in manual mode
3.3 Traversing axes
Milling
Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
123
3. Press keys 1, 10, etc. up to 10000 in order to move the axis in a
defined increment.
The numbers on the keys indicate the traverse path in micrometers or
micro-inches.
Example: Press the "100" button for a desired increment of 100 μm (=
0.1 mm).
;
4. Select the axis to be traversed.
5. Press the <+> or <-> key.
Each time you press the key the selected axis is traversed by the
defined increment.
Feedrate and rapid traverse override switches can be operative.
Note
When the control is switched on, the axes can be traversed right up to the limits of the
machine as the reference points have not yet been approached and the axes referenced.
Emergency limit switches might be triggered as a result.
The software limit switches and the working area limitation are not yet operative!
The feed enable signal must be set.
Machine manufacturer
Please refer to the machine manufacturer's specifications.
