Simulating machining

5.2 Simulation before machining of the workpiece

Milling

180 Operating Manual, 03/2010, 6FC5398-7CP20-1BA0

3. Press the <INPUT> or <Cursor right> key.

- OR -

Double-click the program.

The selected program is opened in the "Program" operating area.

4. Press the "Simulation" softkey.

The program execution is displayed graphically on the screen. The

machine axes do not move.

5. Press the "Stop" softkey if you wish to stop the simulation.

- OR -

Press the "Reset" softkey to cancel the simulation.

6. Press the "Start" softkey to restart or continue the simulation.

Note

Operating area switchover

The simulation is exited if you switch into another operating area. If you restart the

simulation, then this starts again at the beginning of the program.
