Creating G code program
6.6 Blank input
Milling
204 Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
Parameter Description Unit
Data for Selection of the spindle for blank
Main spindle
Counterspindle
Note:
If the machine does not have a counterspindle, then the entry field "Data for" is not
applicable.
Blank
Selecting the blank
Cuboid
Tube
Cylinder
Polygon
Centered cuboid
Delete
X0 1. Rectangular point X - (only for cuboid)
Y0 1. Rectangular point Y - (only for cuboid)
X1 2. Rectangular point X (abs) or 2nd rectangular point X referred to X0 (inc) - (only for
cuboid)
Y1 2. Rectangular point Y (abs) or 2nd rectangular point Y referred to Y0 (inc) - (only for
cuboid)
ZA Initial dimension
ZI Final dimension (abs) or final dimension in relation to ZA (inc)
ZB Machining dimension (abs) or machining dimension in relation to ZA (inc)
XA Outside diameter – (only for tube and cylinder) mm
XI Inside diameter (abs) or wall thickness (inc) – (only for tube) mm
N Number of edges – (only for polygon)
SW or L Width across flats or edge length – (only for polygon)
W Width of the blank - (only for centered cuboid) mm
L Length of the blank - (only for centered cuboid) mm
