Creating a ShopMill program

7.17 Example, standard machining

Milling

Operating Manual, 03/2010, 6FC5398-7CP20-1BA0

249

3. Outside contour of the workpiece

1. Press the "Milling", "Multi-edge spigot" and "Rectangular spigot"

softkeys.

2. Enter the following technology parameters:

T MILLER20 D1 F 0.14 mm/tooth V 240 m/min

3. Enter the following parameters:

Position of reference

point

Bottom left

Machining Roughing (∇)

Type of position Single position

X0 0 abs

Y0 0 abs

Z0 0 abs

W1 185 (fictitious blank dimension)

L1 185 (fictitious blank dimension)

W 180 abs

L 180 abs

R 10 abs

α0 0 degrees

Z1 20inc

DZ 5

UXY 0

UZ 0

4. Press the "Accept" softkey.
