Programming technological functions (cycles)
8.1 Drilling
Milling
Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
267
Parameters, G code program Parameters, ShopMill program
PL Machining plane T Tool name
RP Retraction plane mm D Cutting edge number
SC Safety clearance mm F Feedrate mm/min
mm/rev
S / V Spindle speed or constant
cutting rate
rpm
m/min
Parameter Description Unit
Machining
position (only
for G code)
Single position
Drill hole at programmed position
Position pattern
Position with MCALL
Z0 (only for G
code)
Reference point Z mm
Centering
Diameter (centered with reference to the diameter)
The angle for the center drill entered in the tool list is applied.
Tip (centered with reference to the depth)
The drill is inserted into the workpiece until the programmed insertion depth is
reached.
mm
∅ It is inserted into the workpiece until the diameter is correct. - (for diameter centering
only)
mm
Z1
Drilling depth (abs) or drilling depth in relation to Z0 (inc)
It is inserted into the workpiece until it reaches Z1 - (for tip centering only)
mm
DT
Dwell time (at final drilling depth) in seconds
Dwell time (at final drilling depth) in revolutions
s
rev
