Programming technological functions (cycles)
8.2 Milling
Milling
302 Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
Machining type
You can select the machining mode for milling the circular spigot as follows:
● Roughing
Roughing involves moving round the circular spigot until the programmed finishing
allowance has been reached.
● Finishing
If you have programmed a finishing allowance, the circular spigot is moved around until
depth Z1 is reached.
● Chamfering
Chamfering involves edge breaking at the upper edge of the circular spigot.
Procedure
1. The part program or ShopMill program to be processed has been
created and you are in the editor.
2. Press the "Milling" softkey.
3. Press the "Multi-edge spigot" and "Circular spigot" softkeys.
The "Circular Spigot" input window opens.
Parameters, G code program Parameters, ShopMill program
PL Machining plane T Tool name
Milling direction D Cutting edge number
RP Retraction plane mm F Feedrate mm/min
mm/rev
SC Safety clearance mm S / V Spindle speed or constant
cutting rate
rpm
m/min
F Feedrate mm/min
Parameter Description Unit
FZ
(only for G code)
Depth infeed rate mm/min
Machining
∇ (roughing)
∇∇∇ (finishing)
Chamfering
Machining
position
Single position
A circular spigot is machined at the programmed position (X0, Y0, Z0).
Position pattern
Several circular spigots are machined in a position pattern
(e.g. full circle, pitch circle, grid, etc.).
