Programming technological functions (cycles)
8.3 Contour milling
Milling
Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
331
Cartesian starting point
1. Enter the starting point for the contour.
2. Enter any additional commands in G code format, as required.
3. Press the "Accept" softkey.
4. Enter the individual contour elements.
Polar starting point
1. Press the "Pole" softkey.
2. Enter the pole position in Cartesian coordinates.
3. Enter the starting point for the contour in polar coordinates.
4. Enter any additional commands in G code format, as required.
5. Press the "Accept" softkey.
6. Enter the individual contour elements.
Parameter Description Unit
PL Machining plane
X
Y
Cartesian:
Starting point X (abs)
Starting point Y (abs)
mm
mm
X
Y
Starting point
L1
ϕ1
Polar:
Position pole (abs)
Position pole (abs)
Distance to pole, end point (abs)
Polar angle to the pole, end point (abs)
mm
Degrees
mm
Degrees
Additional
commands
The contour is finished in continuous-path mode (G64). As a result, contour transitions
such as corners, chamfers or radii may not be machined precisely.
If you wish to avoid this, there is a possibility to use additional commands when
programming.
Example: For a contour, first program the X parallel straight line and then enter "G9"
(non-modal exact stop) for the additional command parameter. Then program the Y-
parallel straight line. The corner will be machined exactly, as the feedrate at the end of
the X-parallel straight line is briefly zero.
Note:
The additional commands are only effective for path milling!
