Programming technological functions (cycles)
8.5 Contour turning - only for G code programs
Milling
392 Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
Parameters, G code program
PRG Name of the program to be generated
PL Machining plane
RP Retraction plane mm
SC Safety clearance mm
F Feedrate mm/min
Residual
material
With subsequent residual material removal
Yes
No
CONR Name to save the updated unmachined-part
contour for residual material removal
Parameters Description Unit
Machining
∇ (roughing)
∇∇∇ (finishing)
Face
Longitudinal
Parallel to the contour
From inside to outside
From outside to inside
From end face to rear side
From rear side to end face
Machining
direction
The machining direction depends on the stock removal direction and choice of tool.
Position
front
back
internal
external
D Maximum depth infeed - (only for ∇) mm
DX Maximum depth infeed - (only for parallel to the contour, as an alternative to D) mm
Do not round contour at end of cut.
Always round contour at end of cut.
Uniform cut segmentation
Round cut segmentation at the edge
