Programming technological functions (cycles)
8.6 Further cycles and functions
Milling
Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
417
Machining methods
With the "High Speed Settings" function, you can select between four technological
machining types:
● "Finishing"
● "Rough-finishing"
● "Roughing"
● "Deselected" (default setting)
For CAM programs in the HSC range, the four machining types directly relate to the
accuracy and speed of the path contour (see help screen).
The operator/programmer uses the tolerance value to give a corresponding weighting.
Corresponding to the appropriate G commands, the four machining types are assigned to
technology G group 59:
Machining type Technology G group 59
Deselection DYNNORM
Finishing DYNFINISH
Rough-finishing DYNSEMIFIN
Roughing DYNROUGH
Additional G commands that are available in conjunction with machining free-form surfaces,
are also activated in the High Speed Settings cycle.
When deselecting CYCLE832, the G groups are programmed to the settings - during the
program run time - that are declared in the machine data for the reset state.
References
For additional information, please refer to the following documentation:
Commissioning Manual SINUMERIK Operate / SINUMERIK 840D sl
Machine manufacturer
Please refer to the machine manufacturer's specifications.
Procedure
1. The part program or ShopMill program to be processed has been
created and you are in the editor.
2. Press the "Various" softkey.
3. Press the "High Speed Settings" softkey.
The "High Speed Settings" input window is opened.
