Tool management

12.8 Magazine

Milling

Operating Manual, 03/2010, 6FC5398-7CP20-1BA0

487

Magazine list icons

Icon/

Designation

Meaning

Tool type

Red "X"

The tool is disabled.

Yellow triangle pointing

downward

The prewarning limit has been reached.

Yellow triangle pointing

upward

The tool is in a special state.

Place the cursor on the marked tool. A tooltip

provides a short description.

Green border

The tool is preselected.

Magazine/location number

Green double arrow

The magazine location is positioned at the change

position.

Gray double arrow

(configurable)

The magazine location is positioned at the loading

position.

Red "X"

The magazine location is disabled.

Procedure

1. Select the "Parameter" operating area.

2. Press the "Magazine” softkey.

See also

Displaying tool details (Page 493)

Changing a tool type (Page 494)
