Tool management
12.8 Magazine
Milling
Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
489
Procedure
1. The magazine list is opened.
2. Position the cursor on the tool that you wish to relocate to a different
magazine location.
3. Press the "Relocate" softkey.
The "... relocate from location ... to location ..." window is displayed.
The "Location" field is pre-assigned with the number of the first empty
magazine location.
4. Press the "OK" softkey to relocate the tool to the recommended
magazine location.
- OR -
Enter the required magazine, enter the location number and press the
"OK" softkey.
- OR -
Enter the number "9998" or the number "9999" into the "... magazine"
field in order to select the buffer as well as the required buffer location
in the "Location" field.
- OR -
Press the "Spindle" softkey to load a tool into the spindle and press
the "OK" softkey.
The tool is relocated to the specified magazine location, in the spindle
or in the buffer.
Several magazines
If you have set up several magazines, then the "...relocate from magazine... location... to..."
window appears after pressing the "Relocate" softkey.
Select the desired magazine and location, and confirm your selection with "OK" to load the
tool.
