Program management
13.12 Backing up data
Milling
Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
521
Procedure
1. Select the "Start-up" operating area.
2. Press the "System data" softkey.
The data tree opens.
3. In the data tree, select the required files from which you want to
generate an archive.
- OR -
If you want to back up several files or directories, press the "Select"
softkey and, using the cursor keys or the mouse, select the required
directories or files.
4. If you press the ">>" softkey, further softkeys are displayed on the
vertical bar.
5. Press the "Preview window" softkey.
The contents of the selected file are displayed in a small window.
Press the "Preview window" softkey again to close the window.
6. Press the "Properties" softkey.
Information about the selected file is displayed in a small window.
Press the "OK" softkey to close the window.
7. Press the "Archive" and "Generate archive" softkeys.
The "Generate Archive: Select Archiving" window opens.
All the files to be archived and the storage path are displayed.
8. Select the required location for archiving and press the "New
directory" softkey to create a suitable subdirectory.
The "New Directory" window opens.
9. Enter the required name and press the "OK" softkey.
The directory is created subordinate to the selected folder.
10. Press the "OK" softkey.
The "Generate Archive: Name" window opens.
11. Select the format (e.g. archive ARC (binary format)), enter the desired
name and press the "OK" softkey to archive the file/files.
A message informs you if archiving was successful. An archive file in
.arc format is created in the selected directory.
