Program management
13.13 Setup data
Milling
524 Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
Data
Basic zero points
No
Yes
Directory The directory is displayed, in which the selected program is
located.
File name Here you have the option of changing the suggested file
names.
Note
Magazine assignment
You can only read out the magazine assignments if your system provides support for loading
and unloading tool data to and from the magazine.
Procedure
1. Select the "Program Manager" operating area.
...
2. Position the cursor on the program whose tool and zero point
data you wish to back up.
3. Press the ">>" and "Archive" softkeys.
4. Press the "Setup data" softkey.
The "Backup setup data" window opens.
5. Select the data you want to back up.
6. When required, change the specified name of the originally
selected program here in the "File name" field.
7. Press the "OK" softkey.
The setup data will be set up in the same directory in which the
selected program is stored.
The file is automatically saved as INI file.
