Simrad SU90 Installation Manual

SimradSU90
3ClicktheInstallationMenubutton.
4ObservethattheInstallationmenuappearsatthetopofthedisplay.
Selectingsynchronisationport
Purpose
Thisprocedureexplainshowtodenewhichserialporttouseforsynchronisationwith
otherhydroacousticsystems.
Procedure
1OpentheInstallationmenu.
2SelectI/OSetup→Externalsync.
3VerifythattheSyncPort
Congurationparameterdialogopens.
4ClickPorttochoosewhichseriallineporttouse.
NocommunicationparametersarerequiredsinceonlytheCTSandRTSconnections
areused.
5ClickClosetosavetheselectionandclosethedialog.
6ClosetheInstallationmenu.
Selectingsynchronisationmode
Purpose
ThisprocedureexplainshowtosetuptheSU90tooperateasaslaveormasterdevicein
asynchronisedsystem.
Prerequisites
Itisassumedthattherequiredcablinghasbeenmade,
thattheconnectionshavebeentestedforcontinuity,
andthattheapplicableporthasbeenchoseninthe
Installationmenu.Theperipheralsystem(s)thatshall
controlorbecontrolledbytheSU90mustbepowered
upandoperational.
Procedure
1ClicktheSetuptabtoopenthemenu.
2ClickExternalSynctoopentheparameterdialog.
ThesynchronizationfeatureallowsyoutosetuptheSU90sothatitnevertransmits
whenanothersonarisreceivingechoes,orviceversa.Youcanalsosynchronizethe
SU90tootherhydroacousticsystemsonyourvessel,suchasechosounders.
Whensynchronized,theSU90caneitherbeaMasteroraSlave.
3ClickSyncmodetodenethedesiredmode.
136
381293/A
