Simrad SU90 Installation Manual

SimradSU90
C5SU90/C05ACmainstoOperatingPanelpowersupply
Thiscableisprovidedwiththepowersupply,itisoftenphysicallyxedtothe
unit.
TheotherendisterminatedinanACconnectorsuitableforthechosen
UninterruptedPowerSupply(UPS)system.Ifthisisnotthecase,youmust
replacetheACconnector.Thetypicalcablelengthisbetween1,5and2meters.
Ifthisistooshortyoumustuseanextensioncable(notrecommended),movethe
UPSunit(s)withinrange,ormakeyourownpowercable.
→ConnectingtheOperatingPanelPowerSupplytotheProcessorUniton
page105
→ACmainswithIEC60320socketandinlineplugonpage296
→ACmainswithIEC320/C7inlineplugonpage298
C6SU90/C06GroundcableforProcessorUnit
Thisisastandardcommercialgroundingcable.Whenapplicable,connectthis
cablebetweentheunitandships'ground.Thecablemustbeprovidedbythe
installationshipyard.
→ConnectingACmainsandgroundtotheProcessorUnitonpage106
→Vesselgroundonpage295
C7SU90/C07GroundcableforOperatingPanel
Thisisastandardcommercialgroundingcable.Whenapplicable,connectthis
cablebetweentheunitandships'ground.Thecablemustbeprovidedbythe
installationshipyard.
→ConnectinggroundtotheOperatingPanelonpage108
→Vesselgroundonpage295
C8SU90/C08EthernetcablefromProcessorUnittoTransceiverUnit
ThisEthernetconnectionismadebetweentheProcessorUnitonthebridgeand
theTransceiverUnitinthesonarroom.
Minimumonecablemustbeconnected,twoparallelEthernetcablesmaybeused
toprovideredundancy.EachcablemustbeahighqualityEthernetcable.They
canbeprovidedbytheinstallationshipyard,ororderedfromSimrad.
→ConnectingtheProcessorUnittotheTransceiverUnitonpage109
→RJ45Ethernet,straightonpage300
Note
ItisveryimportantthatahighqualityEthernetcableisused.Youmustuse
CAT-5Equalityorbetter.Cableswithlowerbandwidthcapacitywillreduce
theSU90performance.
96
381293/A
