VA Motion Controller Programming Manual
169
IN2
(
N
)
ANY_INT
Number of digits shifted to the right
OUT
ANY_BIT
As a result, when the value of the pin IN or N changes, it is
shifted to the right. Move two digits to the right, as follows
The value before the right movement
0
0
0
0
0
0
1
1
Value after moving right
0
0
0
0
1
1
0
0
Funtion and Action examples
The value
16 # 50
(
BYTE
)
right shifted three
description
When the contact
C300
is
ON
when this
instruction is executed,
The address
V538
all the bits to the
right
3
bits:
Execution result:
1 6#50
moves
3
bit output to
the right
16 #0A
:
10.1.39 SIN (sinusoidal command )
IL programming
language
LD, FBD programming language
Function: The SIN instruction is used to find the sine of the input value.
LD IN
SIN
ST OUT
ST programming
language
OUT:=SIN ( IN )
Note :
IL, ST
language programming needs to insert variables
IN
and
OUT
or use
constants in the current
POU
variable worksheet
Data type processed by SIN instruction
Input and
output
type of data
description
