Vector VEC-VA Series User Manual

VA Motion Controller Programming Manual
551
11.7.2 NC_MoveLiner (linear interpolation)
FB / FC
Explanation
Applicable model
FB
This instruction is used to control axis linear
interpolation function
VEC-VA-MP-005-
MA
 Input parameters
Name
Features
type of data
Predetermin
ed area
(Default
value)
The timing
of the entry
into force
AxesGroup
(Axis group
number)
Purports to set the axis
of the group can
USINT
0
When
the Execute
from
FALSE to
TRUE
Execute
(Execute bit)
When the Execute
FALSE to TRUE, the
execution instruction
BOOL
TRUE or
FALSE
-
Stop
(Stop Bit)
When a Stop FALSE to
TRUE, the command to stop.
BOOL
TRUE or
FALSE
-
Pause
(Pause
position)
When Pause is TRUE,
suspend execution of the
instruction
BOOL
TRUE or
FALSE
-
MoveMode
(Movement
When is MoveMode
When TRUE, the target
BOOL
TRUE or
FALSE
When
the Execute
