Vector VEC-VA Series User Manual

VA Motion Controller Programming Manual
535
11.6.10 NS_CC_EXTI (DI interrupt instruction)
FB / FC
Explanation
Applicable model
FB
An interrupt is generated when the specified effective
DI, correlate events program will be executed once
VEC-VA-MP-005-
MA
 Input parameters
name
Features
type of data
Setting range
(Non-default)
The
timing of
the entry
into force
DI_ID
When
specifying DI active
interrupt, the input
value of 0 to 7
corresponding to the
input points I0 ~ I7,8
~ 15 corresponding
to the input point I10
~ I17
WORD
Currently only
supports two interrupt
DI0 and DI1
0 to 1
(Non-default)
Enable
When the
Enable FALSE to
TRUE, the command
execution (open
interrupts allowed).
BOOL
TRUE or FALSE
Event_ID
Set interrupt
event number (0-5)
is consistent with the
interrupt routine
event number.
WORD
0-5 (non-default)
