Vector VEC-VA Series

VA Motion Controller Programming Manual
309
11.4.4 MC_MoveAdditive (additional displacement
instruction)
FB /
FC
Explanation
Applicable
model
FB
This instruction from the control shaft in accordance with
the set speed, acceleration and deceleration moved a additional
VEC-VA-M
P-005-MA
 Input parameters
name
Features
type of
data
Range
setting (default
value)
The timing of
the entry into force
Axis
(axis number)
Setting instruction
to be controlled axes
USINT
Analog /
Pulse:
0-4 (real axis)
5 to 11
(imaginary axis)
CANopen
mode: 0-15 (real
axis / imaginary
axis)
(0)
Exexcute from
FALSE to TRUE
Execute
When the Exexcute
FALSE to TRUE, the
instruction execution
starts.
BOOL
TRUE or
FALSE
(FALSE)
-
Continuous
Updata
Retention
-
-
-
Distance
(distance)
Goal Setting
distance
LREAL
Positive,
negative, zero
Exexcute from
FALSE to TRUE
