Vector VEC-VA Series User Manual

VA Motion Controller Programming Manual
477
11.5.13 MC_CamOut (electronic cam departing instruction)
FB / FC
Explanation
Applicable model
FB
This instruction is used to release a relationship
between two electronic cam shafts established
VEC-VA-MP-005-MA
 Input parameters
name
Features
type of
data
Predetermine
d area
(Default
value)
The timing
of the entry
into force
Slvae
(Slave axis)
Set from the
electronic cam shaft
USINT
Analog /
Pulse:
0-4 (real axis)
5 to 11
(imaginary axis)
CANopen
mode: 0-15 (real
axis / imaginary
axis)
(0)
Exexcute
from FALSE to
TRUE
Execute
(Execute bit)
When the Execute
FALSE to TRUE, the
instruction execution starts
BOOL
TRUE or
FALSE
(FALSE)
 Output parameters
name
Features
type of
Output range
