Vector VEC-VA Series User Manual

VA Motion Controller Programming Manual
196
When the contact
C031
is
ON
time ; the
instruction is executed;
The address
V034
in the
16
hex into the
number of
BOOL
, stored in the
V035
in ;
Execution results:
16#OA
to
BOOL
type
Note : As long as the number
in
V034
is not zero,
V035
outputs
1
(
TRUE
)
10.3.7 Conversion of WORD Data
Type conversion FU
Features
WORD
type data
conversion
WORD
-converted data has
. 11
instructions can
be
WORD
respectively converted to data type
BOOL, BYTE, DWORD,
SINT, INT, DINT, USINT, UINT, UDINT, REAL
and
LREAL
other types.
 WORD
conversion instruction type data
instruction
input
value
output
value
description
WORD_TO _BOOL
WORD
BOOL
The input value ranges from 0 to
65,535.
The output is BOOL type :
the output is FALSE only when the input
is 0 , and the output is TRUE in other
cases ;
The output
is SINT type : input 0~127 corresponds
to output 0~127 ,
input 128~255 corresponds to
output -128~-1 , input increases and
output will repeat 0~127 , -128~-1;
Output USINT , BYTE Type : Input 0
to 255 corresponding to the output of 0
to 255 , the input further increasing the
output will be repeated from 0 to
255; output INT type : Input 0 to
32767 corresponding output of 0 to
32767, input from 32768 to
65535 corresponding to the output -
32768~-1; When the output is WORD,
DWORD, etc., the output is equal to
the input.
WORD_TO_BYTE
WORD
BYTE
WORD_TO_DWORD
WORD
DWORD
WORD_TO_SINT
WORD
SINT
WORD_TO_INT
WORD
INT
WORD_TO_DINT
WORD
DINT
WORD_TO_USINT
WORD
USINT
WORD _TO_UINT
WORD
UINT
WORD _TO_UDINT
WORD
UDINT
WORD _TO_REAL
WORD
REAL
WORD_TO_LREAL
WORD
LREAL
