Vector VEC-VA Series User Manual

VA Motion Controller Programming Manual
547
11.6.13 RTC_S (special register clock)
address
Explanation
Applicable models
Special register
And reading the motion controller
for modifying an internal clock
VEC-VA-MP-005-MA
Write clock address
Special register address
Write Functions
Value range
% MB3.9543
year
0 to 255
% MB3.9544
month
0 to 255
% MB3.9545
day
0 to 255
% MB3.9546
week
0 to 255
% MB3.9547
Time
0 to 255
% MB3.9548
Minute
0 to 255
% MB3.9549
second
0 to 255
Special Note:Due to the special register address of byte type, maximum value is larger than
the value of the register 255 overflows, a modulo operation need to be greater than the value of If.
For example, 2018, 2018 can not be filled, it is necessary to 100% by 2018 (modulo)% MB3.9543
to address this in the values   into the register address is the address value in the display 18;
Read clock address
Special register address
Read function
Value range
% MB3.9550
year
0 to 255
% MB3.9551
month
0 to 255
% MB3.9552
day
0 to 255
% MB3.9553
week
0 to 255
% MB3.9554
Time
0 to 255
% MB3.9555
Minute
0 to 255
% MB3.9556
second
0 to 255
Perform the modification Clock Address
Special
register address
Features
Value
range
% MB3.9542
1 when the value of the clock execution modification
(the need to maintain an approximately 1s, the clock needs
to modify the bytes successfully written as 0)
0 to 255
