VA Motion Controller Programming Manual
87
7. 7. Program download to PLC / simulation
1 ) In the communication After setting, click the Toolbar " Project control dialog
window " , pop-up to "Resources" panel , click download, the already completed projects
downloaded to the emulator on the device , downloading process there download progress , as
shown.
2 ) After the program "Download" is completed, click the "Cold Start" program on the
resource panel to run, and the status display "Run" indicates that the user program is continuously
looping; the user can debug online, monitor the status of the variable, click "Debugging on " on
the toolbar , Screen effect during simulation , as shown.
